CP 155-LS/AP
Concept Patio 155 Lift & Slide, Burglar Proof
Sophistication for quality and insulation
Concept Patio® 155 is a premium insulated sliding system with elevated performances. The sophisticated concept fulfils the users high expectations of optimum quality, high insulation and ease of operation. The system gives a lot of design freedom by allowing very large dimensions up to 3 meters in height and up to a vent weight of 400 kg. Thanks to the “High Insulation” upgrade, the system can achieve superior levels down to 1,07 W/m²K (Uf-value). This results in a glazed element with insulation values lower than 1,0 W/m²K, allowing the CP 155-HI system, which is certified with a Minergie label, to be used for low energy buildings. Furthermore the system is available with a low threshold that creates a perfect continuity between the indoor and outdoor spaces and improves the accessibility to the building. This accessibility and comfort is further improved by the solutions for automatic opening.
Technical information
Min. Visible width T-profile 76 mm
Visible width meeting section 115 mm
Max. height vent 3000 mm
Max. width vent 2700 mm
Max. weight vent (element) 400 kg
Overall system depth frame 155 mm
Overall system depth vent 68 mm
Rebate height 25 mm
Visible height vent 102 mm
Min. Glass thickness 4 mm
Max. Glass thickness 52 mm
Thermal break Fibreglass Reinforced Polyamide Strips
Comfort
Air tightness max. test pressure 4 (600 Pa)
Water tightness E900 (900 Pa)
Wind load resistance C3 (1200 Pa)
Acoustic performance Rw (C; Ctr) = 35 (-2;-5) dB / 42 (-1;-3) dB, depending on glazing type dB
Safety
Burglar resistanceWK2
RC2/WK2
Energy
Thermal insulation (Uf)2,0 W/m²K
