950 Hybrid

Winco > Our products > Roller Shutter Systems > 950 Hybrid

950 Hybrid

 the newest EUROPA roller shutter system.

Aluminium Alloy
AIMgSi-0.5 F22

Hardness
12 Webster

Minimum coating thickness
75μm

Profile thickness
1,3 – 1,7mm

Tolerance according to
EN 12020-02

Factor of thermal conductivity for box
Usb=1.2 – 1.5W/m2 K

Maximum dimensions
Width: up to 4,5m
Height: up to 3m

Dimensions of superjacent roller shutter box
140mm,180mm, 200mm, 220mm, 240mm, 260mm

Dimensions of Hybrid superjacent roller shutter box
144mm, 180mm,184mm, 204mm, 210mm, 224mm, 244mm, 264mm

Dimensions of external roller shutter box
140mm, 180mm, 200mm

Aluminium slat profiles
9.3 x 40.2, 9.2 x 40, 10 x 37, 13 x 50.1

Aluminium slat profiles with large groove punching
7.5 x 27

Aluminium slat profiles with polyurethane foam
7.7 x 39.5 και 7.9 x 45mm

950 Hybrid

EUROPA 950 Hybrid is the newest EUROPA roller shutter system.  EUROPA also offers the 990 and 999 series, with or without thermal insulation (Hybrid).

It offers increased thermal insulation up to 1,2w/m2k, while PC (Polycarbonate) sides provide extra stress resistance and remarkable reduction in thermal transmittance. The EUROPA 950 Hybrid series are available in 2 straight boxes 180 and 210 mm. The special design reduces manufacturing time, while providing better fit and smoother rolling.
