ElementFaçade 7 Industrial
The ElementFaçade 7 optimises industrialised fabrication by introducing the straight-cut corner connection. Which brings the much-needed certainty, accuracy, and execution time. This way, our ElementFaçade 7 now becomes available for a wide range of partners and for buildings of all sizes. Any type of fabricator can set up their workshop in a highly flexible way. Anything is possible, from a basic machine setup for 10m² residential projects, up to an industrialized production unit for massive projects of 100.000m² or more.
ElementFaçade 7 is a versatile system, as next to the clear benefits of the straight cut, the traditional mitre cut remains available as an option.
Technical information
Visible width exterior 75 mm
Max. Inertia mullions (lx: wind load) 514 cm⁴
Min. Inertia transoms (lx: wind load) 225 cm⁴
Max. height vent 3700 mm
Max. width vent 2700 mm
Rebate height 12.5 mm
Min. Glass thickness 26 mm
Max. Glass thickness 63 mm
Glazing method Dry glazing with EPDM or neutral silicones
Comfort
Air tightness max. test pressure AE 1200 (1200 Pa)
Water tightness E1200 (1200 Pa)
Wind load resistance 2400 Pa
Acoustic performance Rw(C;Ctr) = 43(-2;-4) dB
Energy
Thermal insulation (Uf) 1.3 W/m²K
