MasterLine 8 Panel Door
Flush Doors
Superb air tightness and insulation
MasterLine 8 panel doors are the ideal solution for domestic entrance doors. With the insulated panels and robust profiles, these doors meet the modern requirements with regard to safety, thermal insulation and stability, allowing the creation of large entrance doors. MasterLine panel doors are available as inward and outward doors, with a freedom of design for the panels, even spy windows are possible. The doors can be fitted with a wide range of locks and hinges.
MasterLine panel doors are designed to meet the modern comfort requirements. The excellent air tightness and superb thermal performances are proven by the Passive Housing certificate that has been awarded to these panel doors.
Technical information
Min. Visible width frame: outward opening 42.5 mm
Max. height vent 3000 mm
Max. width vent 1400 mm
Overall system depth frame 77 mm
Overall system depth vent 77 mm
Min. Glass thickness 6 mm
Max. Glass thickness 63 mm
Glazing method Dry glazing with EPDM or neutral silicones
Thermal break Fibreglass Reinforced Polyamide Strips
Omega Shaped Fibreglass
Comfort
Air tightness max. test pressure 4 (600 Pa)
Water tightness 7A (300 Pa)
Wind load resistance C3 (1200 Pa)
Acoustic performance – dB
Safety
Burglar resistance RC2/WK2
RC3/WK3
