MasterLine 8
Crafted for masters
Max dimensions (HxW)
3000 x 1400 mm
Min. Visible width frame-vent: inward opening
153 mm
Thermal insulation (Uf)
153mm HI: 2,2; HI+: 1,4 (178,5mm HI+: 1,3) W/m²K
Acoustic performance
Rw (C; Ctr) = 43 (-1; -4) dB dB
Water tightness
7A (300 Pa)
Air tightness max. test pressure
4 (600 Pa)
Wind load resistance
C3 (1200 Pa)
Energy level
Passive
Note: Performances may be different depending on the profile combinations.
Crafted for masters
MasterLine 8
Ultimate design freedom. Maximal living comfort.
MasterLine 8 doors offer a wide range of highly insulated and robust flush doors, meeting the modern requirements for safety, thermal insulation and stability, allowing the creation of large entrance doors. MasterLine doors are available as inward and outward opening glass or panel doors and pivoting doors are possible. Passive housing certificate is included in the system.
Variants
More solutions. Discover the design, energy and safety variants.
Consult the detailed specifications, documentation and downloads for all available product variations on the technical product pages.
