CS 77
Optimised safety and comfort
Max dimensions (HxW)
3000 x 1400 mm
Min. Visible width frame-vent: inward opening
150 mm
Thermal insulation (Uf)
150mm: 2,1 W/m²K
Acoustic performance
Rw (C; Ctr) = 42 (-1; -4) dB
Water tightness
7A (300 Pa)
Air tightness max. test pressure
4 (600 Pa)
Wind load resistance
C2 (800 Pa)
Energy level
High
RC2/WK2 – RC3/WK3
Note: Performances may be different depending on the profile combinations.
Optimised safety and comfort
CS 77
A simple and modern solution designed to fit all safety demands.
Concept System® 77 includes a high-quality flush door system, which meets the elevated requirements regarding security, thermal insulation and stability. Different door variants are specially designed and tested for burglar resistance, fire resistance, bullet proof and solutions for panic situations, meeting the most severe European standards.
Variants
A variety of solutions that meet elevated requirements regarding thermal insulation, stability and security.
Consult the detailed specifications, documentation and downloads for all available product variations on the technical product pages.
